Shelters

Material & performance

(1) New type FRP was used as outter and inner skin.

(2) The panel used for the van was constructed in type of sandwich. The middle layer of the sandwich is a kind of new type extruded polystyrene foam. Which offers a very good thermal insulation performance.

(3) The sandwich panel is fixed to the steel frame with high strength adhesive and rivet.

2. Main properties;

(1) Light in weight: 30-40% lighter than domestic traditional products.

(2) Thermal insulation properties: The coefficient of heat conductivity of fiberglass reinforced plastics face panel is about 0.20W/M². K, the coefficient of heat conductivity of hard polyurethane foam is 0.018-0.028W/M². K, and the K #118alue of overall coefficient of heat transference can be below 0.3W/M². K.

(3) Surface properties: Surface of fiberglass reinforced plastics panel possesses very high tensile strength, bending strength and impact ductility. It also possesses excellent chemical stability against rainwater, acid and alkali with low pH #118alue. Therefore, its surface is very smooth, unfading, anti-ultraviolet radiation and easy clearance. Particularly, it is suitable to be used for various carriage advertisements.

(4) Impermeability properties: Both sides of FRP panel possess excellent water impermeability and water resistance.

(5) Fire retardant performance: It conforms to the national standard B1 level.

(6) Service life: 4-6 times longer than domestic traditional products.

(7) Easy maintainability: There is no trace on the panel after repair, which is more competitive than steel and aluminum panels.

(8) Environmental protection properties: There is no volatile and corrodible substance on surface of fiberglass reinforced plastics. And the panels are sandwiched with extruded polystyrene foam plastic without fluorine. It is green environmental protection product.

(9) Refrigerator groups made in USA or German or China can be adopted according to customer's selection to meet different refrigeration property requirements.

Our products have been exported to many countries for years and enjoyed great reputation.

Our oversea markets are as follows: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe etc.
