    Exclusive Condenser Design for Refrigeration Unit Truck System Lower Maintenance Cost

    Ask Lasest Price
    Supply Ability : 300 Sets Per Month
    Certification : ISO9000
    • Product Details
    • Company Profile

    Exclusive Condenser Design for Refrigeration Unit Truck System Lower Maintenance Cost


    Cooler Condenser Evaporator Truck System
    Cooler Condenser Evaporator Truck System
    Cooler Condenser Evaporator Truck System
    Cooler Condenser Evaporator Truck System
    Cooler Condenser Evaporator Truck System
    Cooler Condenser Evaporator Truck System


    Specifications

    Trcuk refrigeration unit SF-T328

    1) keep your goods fresh & cooling
    2)compressor:SD5H14
    3)Automaticaly hot air defrost

    Trcuk refrigeration unit SF-T328

    Main specification

    1.Applicable Temperature : 15~-20
    2.Cooling Capacity:(at 0°c) 2800Kcal/3256W/11109BTU
    Cooling Capacity: (at -18°c) 1750Kcal/2035W/6943BTU
    3.Compressor:

    1)Model: SD5H14 Made in Singapore
    2)Type: Swash plate type
    3)Displacement(cc/r):138
    4)Ludricating:POE


    4.Condenser:
    1)Type:P.F
    2)Fan Type:Axial fan (2fans*1000m3/H)
    3)Voltage:DC12V/DC24V



    5.Evaporator:

    1)Type:inner screw tube and aluminum fin
    2)Fan type:Axial fan
    3)Number of fan 2fan*1000m3/h

    4)Voltage:DC12V/DC24V

    6.Power consuption:Between 33A(DC12V)and 16.5A(DC24V)

    7.Refrigerant:R-134a or R404a
    8.Throttle Type:External equalizer expansion valve
    9.Defrost Type:Automatically hot air defrost
    10.Structure:Spilt direct drive unit
    11.Dimensions(mm) and Weight(kg)


    1) Evaporator:1270*580*170mm(50"*23"*7") and 31.63KG

    2)Condenser :1000*900*170mm(39"*35"*7") and 33.87KG
    ModelSF - 328
    Applicable Temperature (ºC)15 ~ -25
    Cooling CapacityEnvironmental Temperature35°C
    0°C3200Kcal
    -18°C1960Kcal
    CompressorModelQP16
    Displacement(cc/r)168cc
    CondenserTypeP.F.
    Fan TypeAxial fan
    Number of Fan2Fans x 1000m3/h
    VoltageDC 12V/DC24V
    EvaporatorTypeInner screw tube and aluminium fin
    Fan TypeAxial fan
    Number of Fan2 Fans x1000m3/h
    VoltageDC 12V/DC24V
    Power Consumption≤ 30A (DC12V)
    ≤ 18A (DC24V)
    RefrigerantR-134a/R-404a
    Defrost TypeAutomatically hot air defrost
    StructureSplit direct drive unit
    Dimensions (mm) /Net weight(kg)SF-328 EvaporatorL640x W1290x H18030.2 kg
    SF-328 CondenserL520x W1080 x H37028.3kg
    SF-U328 CondenserL640x W1290x H18030.2kg
    SF-U328 CondenserL310 x W885 x H37515.6kg
    Electric Standby system(optional part)AC 220V /AC 380V



    Rest assure that our products are high quality best price and reliable.Our products have been exported to many countries for years and enjoyed great reputation .Our oversea markets are as follows:North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe etc.
